When used in the reverse direction tunnel diodes are called back diodes or backward diodes and can act as fast rectifiers with zero offset voltage and extreme linearity for power signals they have an accurate square law characteristic in the reverse direction.

Define tunnel diode with suitable example. It is a low power device. Thus it is more prone to be damaged by heat and electricity. The germanium material is basically used to make tunnel diodes.

It do not provide isolation between input terminals of diode and output terminals of diode. By using a short antenna feed probe placed in the cavity off center loose coupling is achieved. A tunnel diode is a heavily doped p n junction diode in which the electric current decreases as the voltage increases.

They can also be made from gallium arsenide and silicon materials. The tunnel diode is used as a very fast switching device in computers. Tunnel diode definition is a semiconductor device that has two stable states when operated in conjunction with suitable circuit elements and a source of voltage is capable of extremely rapid transformations between the two by means of the tunnel effect of electrons and is used for amplifying switching and computer information storage and as an oscillator.

It is also used in high frequency oscillators and amplifiers. Leo esaki invented the tunnel diode in august 1957. It is a low cost device.

In tunnel diode electric current is caused by tunneling. Tunnel diode is immune to noise interference. It is simple and it has high speed of operation.

Here is an example of tunnel diode oscillatory circuit. To increase the stability of oscillation and achieve op power over wider bandwidth loose coupling is used. Disadvantages of tunnel diode.

A tunnel diode is also known as eskari diode and it is a highly doped semiconductor that is capable of very fast operation.
